Introduction
This machine is widely used for packaging a variety of items in large, single-piece boxes or for packaging multiple small boxes (with a gold drawstring) in industries such as pharmaceuticals, health supplements, food, cosmetics, stationery, and audiovisual products.
This machine operates by a series of internal servo motors driving various connecting rods and components. It utilizes a multi-function digital display, variable frequency drive, and PLC control technology. It features automatic box feeding, automatic counting, a touchscreen human-machine interface, and vacuum film removal. It can also be connected to other production lines.
Technical Parameters
Packaging speed: 10-40 packs/minute
Maximum pack size: (L) 80-350mm x (W) 50-240mm x (H) 20-120mm
Packaging material: BOPP film and gold wire
Power supply: 380V, 50Hz, 4.5kW
Machine weight: 900kg
Overall dimensions: (L) 2350mm x (W) 1050mm x (H) 1920mm
